Engine: Aluminum Nicasil 50cc with redesigned head stamped with DRR to eliminate imitators.
Carburetor: 21mm PWK D slide performance carb coupled with a high performance intake manifold which features performance fiberglass reeds with flow control adjust ability.
Type:
50cc 2 stroke water cooled.
High torque engine with all new porting for 2012.
Air Cleaner: Trick remote pod filter.
Starting: Electric Start, Kick back-up. No extra $450 charge for what we think should come standard. Real electrical system not wires put in here! This is a safety feature must and keeps those ATVs running like the pros. Save the frustration of trying to kick start your engine. There is nothing worse than watching a kid struggle to start his ATV solve that problem with our free electric start!
Lubrication: Pre Mix only 32 to 1
Transmission:
Re-designed CVT featuring high performance front variator and new improved lightened rear clutch
New forged gear ratio.
Slipper sprocket.
Exhaust: DRX 50R New Exclusive DRR Hole Shot pipe with more torque **
US FORESTRY APPROVED
SPARK ARRESTOR
Safety Features:
CPSC COMPLIANT
Fully enclosed floor boards.
Day running light.
Rear brake light.
Racing safety tether
Gripper Seat
Ergonomic kids size levers
Steering stops
Throttle limiter
ISO 9002.
Front Bumper: Stylish new design to allow extra air flow to the radiator.
Battery: New larger battery
Oil Capacity: 80cc 80W
Fuel tank: 1.32 Gal.
Overall Width: 41" Dual A-Arm
Seat Height: 25"
Wheel Base: 42"
Dry Weight: 232 lbs
Front Brakes: Dual disc wave rotor
Rear Brake:
New for 2012 foot rear foot brake standard plus
Cross drilled disc wave rotor click above description to see pictures
Front Suspension: Dual A-Arm adjustable "DRR Works" AMA compliant piggy back adjustable shocks which feature rebound and cushion adjustment " Real billet aluminum and lock nut adjustment. These shocks took over 2 years to develop.
Rear Suspension: Gas reservoir Remote reservoir Adjustable Mono-Shock "DRR Works" All new for 2012 racing style square tube swing arm. With an additional 2 inches of length for improved handling & performance.
Rims:
Standard Steel Rims
Rear Tires: 18x7x7 Kenda pathfinders
Front Tires: 19x7x7 Razor MX
National Contingency Program
*specifications are subject to change. The ATVs pictured feature after market graphics which are not included.
